Eltako WSZ15DE-32A AC counter

Electronic AC meter AC counters without approval for support rail. Stand-by loss only 0.5 Watt. Accuracy class B (1) % With S0 interface. This alternating current meter measures the active energy on the basis of the current flowing between the input and the output. The own consumption of only a maximum of 0.5 watt active power is not measured and not displayed. Like all counters without PTB or MID approval in Germany not approved for monetary current billing. Every 30 seconds, the display switches from the accumulated active energy to the instantaneous consumption in Watt for 5 seconds. 1 external conductor can be connected with a current up to 32A. In the event of a load to be expected of more than 50%, a ventilation distance of 1/2 division unit is to be maintained for devices mounted next to it. If the spacer DS12 is used. The starting current is 20ma. The display can only be read with power supply. However, the consumption is non-volatile and will be displayed immediately after a power failure. Two N-terminals for secure cross wiring of several counters. The decimal point which flashes depending on the power consumption indicates a power reference. In case of false connection, false appears in the display. The digital display has 7 digits. Up to 99999,99kWh, two descendants are displayed. From 100000.0kWh only one. Even with only theoretically conceivable maximum current reference, the display would be suitable for more than 15 years. The power reference is displayed with the decimal point. TLE: 1 Certified: No Measurement voltage: 230 W
