Selective Part Lock - Switch-Safety Unit INON with Lock, D01-10A

Technical characteristicsRated current:6ANumber of modules:0.5AC voltage:OF 230/415 VInsulation voltage:4,000 VConnection type:Screw technologyTorque:1,2Device life, electrical switching games:6000Machine life mechanical switching games:12000Connection cross section for flexible conductor:6mm2Connection cross section for rigid conductor:10mm2Operating temperature:-25 to 60 °CStorage temperature:-40 to 80 °CHeight installed product:80 mmWide installed product:9.5 mmDeep Installed Product:40 mm

Remote switch 1 Locker 230V AC 16A 1PLEremote switch for pulse control of lighting circuits and others Built according to EN60669-1; EN60669-2-2. Fingerproof according to BGVA2. Contact position display and manual operation. Labeling option directly on the device. Contact type: 1S Number of contacts: 1 Rated current: 16 A Control voltage AC current: 230 V Control voltage DC current: 110 V Number of modules: 1 Operating voltage AC current: 250 V Isolation voltage: 250 V Frequency: 50/60 Hz Connection type: Screw technology Connection cross-section at rigid conductor: 1.5 - 10mm2 Operating temperature: -5 to 40 °C Storage temperature: -40 to 80 °C

Switch 16A 1 Locker 230V AC 1PLE Switch off according to EN 60669-1/669-2-4 with VDE characters, IP2x touch protection according to BGV A3. Suitable for retrofit installation of additional equipment; Labeling option directly on the device. Rated current: 16 ANumber of poles: 1 PNumber of modules: 1AC voltage: 230 VInsulation voltage: 440 VImpact strength: 4000 VFrequency: 50/60 HzConnection type: screw technologyTotal loss power at rated current: 0.4 WMachine life mechanical switching games: 200000Connection cross section for flexible conductor: 1.5 - 10mm2Connection cross section for rigid conductor: 1.5 - 16mm2Operating temperature: -20 to 50 °CStorage temperature: -40 to 80 °CHeight installed product: 83 mmWide installed product: 17.5 mmDeep installed product: 68 mm

Anzahl Module:
1


Lampentyp:
LED


Betriebsnennspannung Wechselstrom:
230 V


Isolationsspannung:
250 V


Stoßspannungsfestigkeit:
4000 V


Frequenz:
50/60 Hz


Anschlussart:
QuickConnect


Gesamtverlustleistung unter Nennstrom:
0,8 W


Anschlussquerschnitt bei flexiblem Leiter:
1,5 - 2,5mm²


Anschlussquerschnitt bei starrem Leiter:
1,5 - 2,5mm²


Betriebstemperatur:
-20 bis 50 °C


Lagerungstemperatur:
-40 bis 80 °C


Höhe installiertes Produkt:
83 mm


Breite installiertes Produkt:
17,5 mm


Tiefe installiertes Produkt:
62 mm

Stair timing switch with low gear. At the time the lighting is limited. Automatic detection of the 3- or 4-wire connection. Hand switch at the Geraet - automatic or continuous lighting. AC voltage: 195/230/253 VFrequency: 50/60 HzContact type: 1SContact Loading: 16A 250V AC1max. Quiet current for probes: 100 mAMax. bulb load: 2300 WControl voltage AC current: 230 VAdjustment range delay time: 30S - 10MinConnection type: screw technologyConnection cross-section with flexible conductor: 1 - 6mm2Connection cross section for rigid conductor: 1.5 - 10mm2Operating temperature: -10 to 55 °CStorage temperature: -20 to 60 °CNumber of modules: 1Protection type: IP20Assembly type: DIN rail (REG)

Smoke detector Standard KRIWAN Q, 3V DC, white. Smoke detectors with small size and attractive design language according to DIN EN 14604 with additional certification according to the increased testing requirements of Q certification based on vfdb guidelines 14-01 “Vereinigung zur Förderung des deutschen Brandschutz” (vfdb). Increased test criteria against the penetration of foreign bodies and increased protection against damp heat, oxidation and EMC, as well as better temperature change stress. Serves for early detection signaling fires with smoke development in the interior. Processor-controlled function self-test (all 10 sec.) and PGSA technology with independent algorythmic night-riggering when disturbing influences occur, such as dust, to maintain functional safety. Large function and reset button through the entire upper cover of the detector. Acoustic signal (85 dB at 3 m) and red flashing LED for alarming. Acoustic signal for battery wake, pollution or interference with acoustic signaling and yellow LED. Timely limited deactivation function of the smoke detection for suppression of deception alarms of the detector for approx. 12 minutes with automatic reset function in normal operation. Error messages can be delayed by 8 hours for 7 days by acknowledgement on the reset button. The fault of a contaminated detection unit cannot be reset as long as the fault message continues to exist in the evaluation unit. Ceiling mounting or wall mounting according to DIN14676. The detector has a camping/caravan registration. Disassembly and theft protection can be activated, then unlocking only with screw rotation with max. Size of 7mm possible. When turning into the socket, the detector is automatically activated.

auxiliary switch 6A 1 closer and 1 opener 230V

Installation relays for pulse control of circuits up to max. 16 A, according to EN 61095 and DIN VDE 0637-3 as well as contact protection according to DIN VDE 0106 part 100. With contact position display by display window, integrated labeling field and suitable for subsequent installation of additional device. Notes: If several devices are installed directly, a spacer (1/2 PLE) must be installed next to each second device.Contact type: 2S nominal current: 16 AControl voltage AC current: 230 V Number of modules: 1 Rated operating voltage Ue: 230 V Frequency: 50/60 Hz

Performance: 4 VAOutput voltage: 8/12 VNumber of modules: 2AC voltage: 230 VInsulation voltage: 4000 VFrequency: 50 HzTotal loss power at rated current: 1.8 WConnection cross section for flexible conductor: 4mm2Connection cross section for rigid conductor: 6mm2Operating temperature: -20 to 35 °CHeight installed product: 111 mmWide installed product: 35 mmDeep installed product: 65 mm

LED light indicator, red, 230VAC, QC rail passage

Remote dimmer 500W Universal, LED/ESL remote dimmer for controlling dimmable energy saving and LED lamps, bulbs, 230V halogen lamps and NV halogen lamps with coiled or electronic Trafo. Automatic load detection Detection method and learning function via external Taster. Memory function is used when switching on Activation of the last set value. With low space requirement and low standby consumption of 0,2W. Remote control of the dimmer by probe also illuminated possible. Electronic short circuit and over- Temperature protection. Frequency: 50/60 Hz Performance: 500 VA Performance of conventional transformer 230 V: 500 VA Power transformer/EVG 230 V: 500 VA Operating temperature: -20 to 50 °C Storage temperature: -20 to 50 °C Number of modules: 2 Protection type: IP20 Assembly type: DIN rail (REG) Load type: universal
