Eaton PFIM-63/4/003-G-MW FI circuit breaker AC 63A/4 30mA 'G' 3kA 235456
zoom_out_map
chevron_left chevron_right

Safety information & warnings:

Risk of electric shock: Installation, connection and commissioning may only be carried out by a qualified electrician in accordance with the applicable installation regulations. Before working, disconnect the supply, secure it against reconnection and verify that it is de-energised.

Risk of fire: Rated current, tripping characteristic, breaking capacity and type must match the installation and the cable cross-section. Incorrectly selected devices may cause fire or personal injury.

Test residual current devices with the test button after installation and regularly thereafter.

Observe the manufacturer's operating and installation instructions. Use only as intended.

Angaben laut EU-Produktsicherheitsverordnung (GPSR):
Hersteller:

Eaton
Eaton Industries (Austria) GmbH
Eugenia 1​ A-3943 Schrems
Tel.: +43 (0) 50868 - 0​
infoaustria@eaton.com

Out-of-Stock

Eaton PFIM-63/4/003-G-MW FI circuit breaker AC 63A/4 30mA 'G' 3kA 235456


235456
4015082354565
Eaton

Number
4
Measurement voltage
V400
Rated current
A63
Measurement error current
A0.03
Assembly type
DIN rail
Error current type
AC
Selective type
no
Short-circuit strength (Icw)
KA10
Impact resistance
KA3
Frequency
50 Hz
Additional equipment possible
yes
Type of protection (IP)
IP20
Size (according to DIN 43880)
1
Width in division units
4
Installation depth
mmANNEX
Short-term delayed type
yes

€141.58 VAT included

€117.98 VAT excluded

block Out-of-Stock
