Wago 2273-208 COMPACT 8x0,5-2.5 Connection box clamp 50 pieces
| Total number of clamping points | 3 | |
| Total number of potentials | 1 | |
| Measurement voltage (II / 2) [V] | 450 | V |
| Measurement surge voltage (II / 2) [kV] | 4 | KV |
| Rated current [A] | 24 | A |
| Connection technology | PUSH WIRE® | |
| Number of connection points | 3 | |
| Type of operation | Push in | |
| Connectable conductor materials | Copper | |
| adhesive, connectable | 0,5 ... 2,5 mm2 / 18 ... 14 AWG | |
| Stripping length | 11 mm / 0.43 in | |
| Type of wiring | Side wiring | |
| Fire load [MJ] | 0,019 | M |
| Weight [g] | 1017 | g |
| Width | 14 mm / 0.551 in. | |
| Height | 5.8 mm / 0.228 in. | |
| Depth | 16.7 mm / 0.657 in. | |
| Safety note 1 | in earthed nets |
