Safety information & warnings:

Risk of electric shock: Installation, connection and commissioning may only be carried out by a qualified electrician in accordance with the applicable installation regulations. Before working, disconnect the supply, secure it against reconnection and verify that it is de-energised.

Risk of fire: Rated current, tripping characteristic, breaking capacity and type must match the installation and the cable cross-section. Incorrectly selected devices may cause fire or personal injury.

Test residual current devices with the test button after installation and regularly thereafter.

Observe the manufacturer's operating and installation instructions. Use only as intended.

Angaben laut EU-Produktsicherheitsverordnung (GPSR):
Hersteller:

Würth Elektrogroßhandel GmbH & Co. KG
Produktbereich PROTEC.class und PROTEC.net
Ludwig-Erhard-Straße 21-39
65760 Eschborn / Ts.
Deutschland
Telefon: +43 0 61 96 / 477- 895
E-Mail: info@protecclass.de

Primo

PROTEC.class PSI NH 2 TR 63 A SECURITY

Name: PROTEC.class PSI NH 2 TR 63 A SECURITY
Brand: Protec
SKU: 5103595
Price: 15 EUR
Availability: InStock

Reference: 5103595

EAN: 4016705135950

Brand: Protec

In accordance with DIN WDE 0636 Part 201, DIN 43620 as well as DIN EN/IEC 60269-1 and DIN EN/IEC 60269-2 Nominal voltage: AC 500 W Portable handle tabs made of metal with hinge detectors. Selectivity factor: 1.6. Operating class (gL)-gG: Full range safety inserts (for cable and cable protection) for general applications. Measurement voltage: 500 W. Measurement switch-off capacity: 120 ka. Measurement frequency: 45 Ö62 Hz. Steatit/Cordierite insulating body. Single-piece full contact knives with surface treatment. Anti-magnetic cover plate made of aluminum alloy. Copper melting ladder. Measurement current: 63 A Size: NH2 Power: 6.8 W

€15.00 VAT included

€12.50 VAT excluded
