Hager MCS113 LS switch 13A/1pol/C 6kA, QC QuickConnect

Circuit breaker 1polig 6kA C-Characteristic 13A Quick Connect 1 module Circuit breaker with QuickConnect terminal according to DIN EN 60898-1 (VDE 0641 part 11):2003-12; EN 60898-1:2003; EN 60898-1, pr A1:2003, at the exit up to 16A and at the access for the concealment up to 63A. LS with time-delayed thermal trigger for overload protection and electromagnetic trigger for short-circuit protection. Suitable for retrofit installation of additional equipment; Possibility of marking directly on the device and individual removal from the phase rail composite by unlocking the quick attachment of the hat rails.

Rated current: 13 A
Trigger characteristic: C
Nominal shutdown capacity: 6 kA
Number of poles: 1 P
Number of modules: 1
AC voltage: 230/400 V
Insulation voltage: 500 V
Frequency: 50/60 Hz
Connection type: QuickConnect
Torque: 2,8Nm
Total loss power at rated current: 2,3 W
Device life, electrical switching games: 4000
Machine life mechanical switching games: 20000
Operating temperature: -25 to 60 °C
Storage temperature: -25 to 80 °C
Height installed product: 83.4 mm
Wide installed product: 17.5 mm
Deep installed product: 70 mm
