Eaton PLSM-C20-MW LS switch 20A/1pol/C 242207



Trigger characteristic
C
Number of poles (total)
1
Number of secured poles
1
Rated current
A20
Measurement voltage
V230
Measurement switching capacity Icn according to EN 60898 at 230 V
KA10
Measurement switching capacity Icn according to EN 60898 at 400 V
KA10
Measurement switching capacity Icu according to IEC 60947-2 at 230 V
KA0
Measurement switching capacity Icu according to IEC 60947-2 at 400 V
KA0
Type of voltage
AC
Energy limiting class
3
Frequency
HZ50 to 60
Interconnecting neutral conductor
no
Suitable for underground installation
no
Overvoltage category
3
Pollution
2
Width in division units
1
Installation depth
mmANNEX
Additional equipment possible
yes
Type of protection (IP)
IP20
