Eaton AFDD-16/2/C/003-A fire protection switch, fault arc protection device 187210
Basic function
|
||||
|
Pole
|
2-pole | |||
|
Trigger characteristic
|
C | |||
|
Application
|
Switching devices for housing and purpose construction | |||
|
Rated current
|
In | A | 16 | |
|
Measurement switching capacity according to IEC/EN 60898-1
|
: | 10 | ||
|
Measurement switching capacity according to IEC/EN 61009
|
: | 10 | ||
|
Measurement short-circuit strength
|
Ic) | : | 10 | |
|
Measurement error current
|
IBY DN | A | 0,03 % | |
|
Type
|
Type A | |||
|
Redemption
|
A | not delayed | ||
|
Type of waste
|
ZV-SS | |||
|
Product range
|
OFDD | |||
|
Sensitivity
|
electrification | |||
|
Impact resistance
|
conditional shock resistant 250 A |
Technical data
| Electric | |||
|
Finished
|
IEC 62606 IEC 61009 |
||
|
Current test marks
|
according to the following conditions: | ||
|
Limits of operating voltage
|
|||
|
Test circuit
|
BY AC | 170 - 264 | |
|
Sensitivity
|
electrification | ||
|
Measurement short-circuit strength
|
Ic) | : | 10 |
|
Life
|
|||
|
electrical
|
Circuit games | 4000 | |
|
mechanical
|
Circuit games | 20000 | |
| Mechanical | |||
|
Cap dimensions
|
mm | 45 | |
|
Approval
|
mm | 80 | |
|
Installation width
|
mm | 54 (3TH) | |
|
Assembly
|
Tristable locking slide allows removal from an existing composite. | ||
|
Type of protection
|
IP20 switch IP40 installed |
||
|
Clamps up and down
|
Mouth/Lift clamps | ||
|
Clamp protection
|
Contact protection according to WBG4, ÖVE-EN 6 | ||
|
Material thickness
|
mm | 0.8 - 2 | |
|
permissible ambient temperature range
|
C | -25 - +40 | |
|
permissible storage or. Transport temperature
|
C | -35 - +60 | |
|
Climate resistance
|
in accordance with IEC/EN 61009 | ||
|
Contact position indicator
|
red / green | ||
